Ortofon SPU ClassicC GM E MKII
Ortofon SPU ClassicC GM E MKII

Ortofon SPU ClassicC GM E MKII

1.299 €
VAT included

MC Capsule

Get register and you will earn 1299 points Get register and you will earn 1299 points

Your cart will total 1299 points that can be converted into a voucher of 13 €.



A variant of the SPU Classic GM mkII equipped with a Nude elliptical stylus designed by Ortofon, the SPU Classic GM E mkII is a moving-coil pickup capsule featuring the characteristic SPU design that provides access to the special sonic magic of this very old transducer concept at a moderate price. It should be said that when the SPU was first introduced in 1958, it offered a superior type of sound to any other pickup capsule on the market for the simple reason that its design was far superior to that of its competitors. Even today, more than half a century later, the SPU still exhibits a sound that definitely has its own personality and continues to enjoy a strong following among audio purists who have a special appreciation for vintage components.

From a technical point of view, the SPU Classic E mkII is based on an evolved version of the two key innovations of the SPU at the time: a signal generator system consisting of two low-impedance coils and the use of extremely thin copper conductors in the windings of these coils, plus the arrangement of the coils so that the two walls of a stereo record's micro-surround generate two discrete signals with maximum channel separation. As a result, the SPU Classic GM E mkII delivers what was once known as the " Ortofon sound", characterised by rich bass and transparent treble, plus a number of qualities that are difficult to define but easy to appreciate once perceived. A genuine classic in audio history.


Features:

  • Very high performance moving coil (MC) capsule.
  • Fully integrated in its dedicated cartridge carrier.
  • Output voltage of 0.2 mV at 1 kHz and 5 cm/s.
  • Frequency response: 20 - 25,000 Hz (-3 dB cut-off points).
  • Recommended Load Impedance: MC / >10 Ohm.
  • Tracking Ability: 65 um (at 315 Hz).
  • Dynamic Compliance: 8 um/mN.
  • Recommended Support Force: 4 grams.
  • For moderate and high mass readout arms with SME connection.
  • Weight: 30 g.
