Ortofon Super OM 5E
Ortofon Super OM 5E

Ortofon Super OM 5E

89 €
VAT included
MM Capsule

Get register and you will earn 89 points Get register and you will earn 89 points

Your cart will total 89 points that can be converted into a voucher of 1 €.



As the top model in the OM 5 Series, the Super OM 5E incorporates distinctive engineering elements aimed at maximising flexibility of use, such as a body designed for easy mounting and fitting to both top- and bottom-mount carriers. A small weighting plate has been included on the top of the mounting bracket to facilitate integration into all types of low-mass readout arms (the plate will be left in place if a standard mass arm is used and removed if a low-mass arm is used).

On the other hand, being compatible with several spare styli, the Super OM 5E is ready to become the perfect complement for all kinds of home audio systems, applications and budgets. In terms of technical solutions, the Super OM 5E's body is made of Noryl, an extremely lightweight plastic and glass composite that ensures high rigidity and immunity to resonance.

In addition, the magnet motor is equipped with the iconic split pole pins from Ortofon, a development that allows moving-magnet capsules to exhibit a frequency response curve as flat as moving-coil (MC) capsules. On the stylus side, the Super OM 5E uses an elliptical profile that allows it to read vinyl grooves with greater accuracy and less distortion as a result of its contoured shape.


Features:

  • Moving Magnet (MM) capsule with an exceptional price/performance ratio.
  • For standard and low mass readout arms.
  • Output voltage of 4 mV at 1 kHz and 5 cm/s.
  • Frequency response: 20 - 25,000 Hz (-3 dB cut-off points).
  • Recommended Load Impedance: MM/47,000 Ohm.
  • Load Capacitance: 200 to 500 pF.
  • Tracking Ability: 65 um (at 315 Hz).
  • Dynamic Compliance: 20 um/mN.
  • Recommended Support Force: 1.75 g.
  • Weight: 5 g.

Replacement needle available for this capsule, ask us for price and availability.
