This is a stereo integrated amplifier with DAC inspired by the QUAD 22 preamplifier and whose aesthetics are clearly reminiscent of the celebrated updates of the 33 and 303 models of the legendary British company.
The beautiful electronics feature the iconic orange backlit LCD function display of the 33, which allows the user to intuitively control the different settings, parameters, options and source selections, all of which are visibly represented.
But these electronics go far beyond maintaining a legacy of timelessness that few other brands can match, including uncompromising connectivity for the modern audiophile. In keeping with QUAD's purist reputation, the 3 is equipped with circuitry that harmonises topologies and components of the highest standard.
On the digital side, we find an ESS9038Q2M D/A converter from California-based ESS Technology followed by a Class A configured circuit, while the critical analogue section features a power supply block centred around a generously shielded toroidal transformer, to which is added a bank of capacitors totalling a capacity of 30,000 uF.
Features:
- Stereo integrated amplifier with an exceptional price/performance ratio.
- Aesthetics inspired by the QUAD 22 preamplifier.
- DAC compatible with PCM up to 32-bit/768 kHz, DSD up to DSD512 and MQA
- Executed with audiophile-grade components.
- Power amplifier circuitry configured in Class AB
- Phono section (MM only) with high-precision RIAA equalisation.
- Separate bass and "Tilt" controls (QUAD exclusive).
- Headphone amplifier with current feedback topology.
- Bluetooth 5.1 wireless connectivity with aptX HD compatibility.
- Continuous output power of 2 x 65 W at 8 ohms or 2x100 W at 4 ohms.
- 20-20,000 Hz frequency response, +/-0.1 dB.
- Maximum current delivery capability of 10 A.
- Input sensitivity of 800 mV Line and 3.6 mV Phono (MM).
- Signal to noise ratio of 116 dB digital, 110 dB line and 78 dB phono.
- Headphone amplifier impedance range: 20-600 ohms.
- Digital inputs optical (1), coaxial (1), USB-B (1) and HDMI ARC (1).
- Dimensions: 300 x 101 x 332 mm (W x H x D).
- Weight: 8 kg.
