MM Capsule

Model

Get register and you will earn 339 points Get register and you will earn 339 points

Your cart will total 339 points that can be converted into a voucher of 3 €.



Designed specifically to extract the maximum juice from the monophonic microgroove recordings that first saw the light of day around 1950, the 2M Mono is a monophonic capsule that takes advantage of the advances introduced in the 2M series to deliver sonic restitution with unique clarity.

To achieve this, it features an 18 um spherical stylus that provides an optimal solution for playing mono vinyl records with microgrooves thanks to the use of an innovative signal generation scheme developed by Ortofon that allows the same output signal to be delivered to either of the two available pairs of connectors.

This effectively eliminates the need to use specific designs for mono systems, making it possible to fully enjoy true mono sound reproduction with any stereo equipment.


Features:

  • High-performance monophonic moving magnet (MM) capsule.
  • Designed for reading vinyl records with microgrooves.
  • Output voltage of 4 mV at 1 kHz and 5 cm/s.
  • Frequency response: 20 - 22,000 Hz (-3 dB cut-off points).
  • Recommended Load Impedance: MM/47 kOhm.
  • Load Capacitance: 150 - 300 pF.
  • Tracking Ability: 70 um (at 315 Hz).
  • Dynamic Compliance: 18 um/mN.
  • Recommended Support Force: 1.8 g.
  • For moderate and low mass reading arms.
  • Weight: 7.2 g.


Verso Version: Same characteristics as the standard version but with the fastening screws already anchored to the capsule and facing upwards.

MR Version: Same features as standard but with a lower weight and lower profile, suitable for turntables such as Rega.

Pre-assembled: Same features as the standard version but already mounted on a black SH-4 type Ortofon cartridge holder.

Available needle replacements Ortofon Stylus 2M Bronze for 349€
